Supports CAN2.0A (standard frame) and CAN2.0B (extended frame).
CAN baud rate is configurable in the range of 5Kbps-1Mbps.
Supports 4 working modes: normal mode, loopback mode, silent mode, silent loopback mode.
Supports multiple CAN data sending modes: single frame, multiple frames, manually, regular and cyclic sending.
Supports multiple CAN data receiving modes: can be configured to only receive data from a certain ID, or specify an ID to automatically answer the configured data.
Data can be saved as TXT or Excel.
Supports CAN bus detection for checking status.
Sending/receiving CAN data with a time scale, allows sequentially displaying.
Baud rate of the USB virtual COM port is configurable in the range of 9600 ~ 2000000bps (2000000bps by default).
Supports set working parameters by configuration software or serial command, can be saved after power off.
Adopts STM32 chip solution, stable and reliable communication.
Onboard TVS (Transient Voltage Suppressor), effectively suppresses surge voltage and transient spike voltage in the circuit.
Comes with the host software for Windows system, easy to use.
Easy secondary development, just need to modify the sending and receiving commands.
